Vanadium Pentoxide Profile

Vanadium Pentoxide Profile

General Information

Vanadium pentoxide, a yellow-red crystalline powder, is the most common form of vanadium.[1] Vanadium is a soft grey metal that may be found in rocks, iron ores, and petroleum deposits.[2] It is most commonly found in nature in compounds with oxygen, sodium, sulphur, or chlorine. Vanadium oxides are released through combustion of vanadium containing ores and petroleum. Vanadium pentoxide may also be referred to as (V2O5), vanadium oxide, divanadium pentoxide, and vanadic acid anhydride. There are numerous other synonyms and product names; see the Hazardous Substances Data Bank (HSDB) for more information.[3]

Vanadium pentoxide was classified by the International Agency for Research on Cancer (IARC) in 2006 as Group 2B, possibly carcinogenic to humans.[4] This classification is based on inadequate evidence of carcinogenicity in humans and sufficient evidence in animals. In one study, inhalation exposure to vanadium pentoxide resulted in an increased incidence of alveolar/bronchiolar neoplasms in mice and male rats.[4] No human data on carcinogenicity were available to the IARC working group.

Additionally, vanadium pentoxide is a respiratory irritant,[2] and at high doses can cause “boilermaker’s bronchitis,” an acute respiratory irritation.[4]

Regulations and Guidelines

Occupational exposure limits (OEL) [5,6,7,8,9,10,11,12,13,14,15,16,17,18,19]

Canadian Jurisdictions OEL (mg/m3)
Canada Labour Code 0.05 [i]
AB, QC 0.05 [r]
BC 0.05 [i]
MB, NL, NS, ON, PE 0.05 [i]
NB, NT, NU, SK 0.05 [r]
0.15 [stel, r]
YT 0.5; 1.5 [stel] for dust
Other Jurisdiction OEL (mg/m3)
ACGIH 2020 TLV 0.05 [i]
mg/m3 = milligrams per cubic meter
i = inhalable fraction
r = respirable fraction
stel = short term exposure limit (15 min. maximum)
c = ceiling (not to be exceeded at any time)
ACGIH = American Conference of Governmental Industrial Hygienists
TLV = threshold limit value

Canadian agencies/organizations

Agency Designation/Position Year
CEPA Schedule 1, paragraphs ‘c’ 2012[20]
Health Canada DSL – high priority substance with the greatest potential for exposure 2006[21]
CMP Challenge Batch 9B for ‘vanadium oxide’ 2008[22]
Environment Canada’s National Pollutant Release Inventory NPRI Part (Threshold Category): 1A, Reportable to NPRI if manufactured, processed, or otherwise used at quantities greater than: 10 tonnes. Total of pure vanadium and the equivalent weight of vanadium contained in any cound or mixture. Excludes vanadium contained in an alloy (for Vanadium and its compounds) 2016[23]
DSL = domestic substances list

Vanadium pentoxide was not included in other Canadian government guidelines, standards, or chemical listings reviewed.

Main Uses

The primary industrial use of vanadium pentoxide is in ferrovanadium, which is then used to produce high strength, low alloy steels.[24] Smaller amounts of vanadium pentoxide are used in titanium-aluminum alloys, which have applications in the aerospace industry.[24] Vanadium compounds are also used in pigments and inks, as colouring agents, and as UV filters in some glasses,[25] as well as in producing plastics, rubbers, ceramics, and other metals.[2]

Vanadium pentoxide is used as an oxidation catalyst in industrial synthesis processes such as manufacturing sulphuric acid,[25] and in catalytic converters for automobiles.[3]

One specialty application for vanadium pentoxide is in Vanadium Redox Batteries (VRB), which are large-scale electrochemical energy storage systems.[24]

Canadian Production and Trade

Canadian market demands for vanadium pentoxide are primarily met through import.[24] Canada has not produced vanadium since the early 1990’s, when a vanadium plant closed in Fort McMurray, Saskatchewan. Vanadium was being produced through recovery from oil sands in the form of vanadic acid (they were expecting to produce vanadium pentoxide later), but the operation ceased due to low prices.[24] China, Russia, and South Africa are the leading world producers of vanadium.[26]

There are three major geological deposits of vanadium in Canada – two in northern Quebec and one in northern Manitoba.[24,27]

There is very little recycling of vanadium; most is obtained from primary sources including recovery from ores, concentrates, slags, or petroleum residues.[26]

Production and trade

Activity Quantity Year
Export 0 t of ‘vanadium oxides and hydroxides’ 2021[28]
Import 2,537 t of ‘vanadium oxides and hydroxides’ 2021[28]
t = tonne

Environmental Exposures Overview

Although food is typically the main source of exposure to vanadium compounds, these compounds are poorly absorbed through the gastrointestinal system.[2] Soil contamination on food can contribute to exposure since soil concentrations can be much higher than air levels, especially near metallurgical plants or other sources.[2] High soil levels are particularly relevant in children prone to ingesting soil.[2]

For people living near a point source, ambient air is the primary source of exposure to vanadium pentoxide.[2] The most significant source of vanadium-contaminated air is oil and coal combustion (90% of total global emissions).[4,25] Levels of vanadium are typically higher near metallurgical plants and in large cities (especially on the heavily-populated eastern seaboard of the US and Canada, where fuel oils are commonly burned in the cold months).[4] Ambient levels may be elevated in port cities due to high levels of vanadium emitted from ships using heavy fuel oil.[29]

Vanadium has been measured in samples of coal and ash from Canadian sources.[30] No consumer products are listed for vanadium pentoxide in the US Consumer Product Information Database.[31]

Searches of Environment Canada’s National Pollutant Release Inventory (NPRI) yielded the following results on current potential for exposure to vanadium pentoxide in Canada:

NPRI reported releases

NPRI 2015[32]
Substance name: ‘Vanadium (except when in alloy) and its compounds’
Category Quantity Industry
Released into Environment 120 t Petroleum and coal product manufacturing,
metal ore mining, oil and gas extraction, electric power generation, transmissions and distribution, iron and steel mills, motor vehicle manufacturing (110 facilities)
Disposed of 21,545 t
Sent to off-site recycling 3,892 t
t = tonne

Occupational Exposures Overview

Inhalation is the most important route of occupational exposure to vanadium pentoxide.[2]

CAREX Canada estimates that approximately 7,600 Canadians are exposed to vanadium pentoxide in their workplaces. The largest industrial groups exposed include fabricated metal products, boiler, tank and shipping container manufacturing, services to buildings and dwellings, and building equipment contractors. The largest occupational groups exposed to vanadium pentoxide are boilermakers, followed by welders, specialized cleaners, and other labourers in processing, manufacturing, and utilities.

Other occupations that may be exposed to vanadium pentoxide are specialized cleaners, industrial mechanics, artisans and craftspersons, petroleum refiners, and ceramicists (where vanadium is used as a pigment).[1]

For more information, see the occupational exposure estimate for vanadium pentoxide.

Sources

1. Agency for Toxic Substances and Disease Registry (ATSDR). ToxFAQs for Vanadium (2012) (PDF)
2. Agency for Toxic Substances and Disease Registry (ATSDR). Toxicological Profile for Vanadium and Compounds (2012) (PDF)
3. Toxicology Data Network (TOXNET). Hazardous Substances Data Bank (Search term: ‘Vanadium pentoxide’)
4. International Agency for Research on Cancer (IARC). Monograph summary, Volume 86 (2006)
8. The Canadian Legal Information Institute (CanLII). Manitoba Regulation 217/2006 Workplace Safety and Health Regulation (2022)
10. Government of Newfoundland and Labrador. Regulation 5,12 Occupational Health and Safety Regulations (2018)
11. Government of the Northwest Territories. Occupational Health and Safety Regulations, R-039-2015 (2020) (PDF)
13. The Canadian Legal Information Institute (CanLII). Government of Nunavut’s Occupational Health and Safety Regulations, Nu Reg 003-2016 (2010)
15. Government of Prince Edward Island. Occupational Health and Safety Act Regulations Chapter 0-1 (2013) (PDF)
17. Government of Saskatchewan. The Occupational Health and Safety Regulations, 1996 (2016) (PDF)
18. The Canadian Legal Information Institute (CanLII). Yukon’s Occupational Health Regulations, O.I.C. 1986/164 (2020) (PDF)
19. Occupational Safety and Health Administration (OSHA). Annotated PELs (2020)
20. Environment and Climate Change Canada. CEPA List of Toxic Substances (2020)
21. Health Canada. Prioritization of the DSL (2006)
24. Environment and Climate Change Canada. Screening Assessment for the Challenge: Vanadium Pentoxide (2010) (PDF)
25. World Health Organization (WHO). CICAD for Vanadium Pentoxide and Other Inorganic Vanadium Compounds (2001) (PDF)
26. US Geological Survey. 2018 Minerals Yearbook (Vanadium) (2021) (PDF)
27. US Geological Survey (USGS). 2015 Minerals Yearbook – Vanadium (2015)
28. International Trade Centre. TradeMap (Free subscription required)
29. California Environmental Contaminant Biomonitoring Program (CECBP). Scientific Guidance Panel (SGP) Vanadium and Vanadium Compounds, meeting notes, Dec 2008 (2008)
30. Mueller D, Uibel S, Takemura M, Klingelhoefer D, Groneberg DA. “Ships, ports and particulate air pollution – an analysis of recent studies”Occup Med Toxicol2011; 6(31):1-6.
31. Consumer Product Information Database. What’s in it?  (Search term: “vanadium pentoxide”) (2022)
32. Environment and Climate Change Canada. National Pollutant Release Inventory (NPRI) Facility Search (Substance name: ‘Vanadium (except when in alloy) and its compounds’)



Other Resources

  1. Cooper R. “Vanadium pentoxide Inhalation.” Indian J Occup Environ Med 2007;11(3):97-102.
  2. US Geological Survey. Mineral Commodity Summary for the United States (Vanadium) (2008) (PDF)
  3. Duffus JH. “Carcinogenicity classification of vanadium pentoxide and inorganic vanadium compounds, the NTP study of carcinogenicity of inhaled vanadium pentoxide, and vanadium chemistry.” Regul Toxicol Pharmacol 2007;47(1):110-114.
