INDUSTRIAL CHEMICALS – POSSIBLE CARCINOGEN (IARC 2B)
Contents
Acrylonitrile Profile
General Information
Acrylonitrile is a volatile, highly reactive, colourless liquid.[1] It is soluble in water and many other common organic solvents.[2] Acrylonitrile does not occur naturally,[3] but has been an important industrial chemical since the 1940s.[1]
Acrylonitrile may also be referred to as vinyl cyanide or cyanoethylene.[4] There are numerous other synonyms and product names; see the Hazardous Substances Data Bank (HSDB) for more information.[4]
Acrylonitrile was classified by the International Agency for Research on Cancer (IARC) in 1999 as Group 2B, possibly carcinogenic to humans, based on evidence in experimental animals.[5] Acrylonitrile was found to cause cancer in rats, with tumours reported in the central nervous system, mammary gland, and a few other rare tumour sites.[5]
Several epidemiological studies in the 1970s and 1980s identified a link between occupational exposure to acrylonitrile and lung cancer, however these findings have not been conclusively confirmed in larger, more recent studies.[5]
Inhalation of acrylonitrile can cause respiratory irritation and, at higher levels, neurological symptoms including dizziness, weakness, headache, and impaired judgment.[6] Dermal exposure can result in skin irritation and blistering.[6]
Regulations and Guidelines
Occupational exposure limits (OEL) [7,8,9,10,11,12,13,14,15,16,17,18,19,20,21]
| Canadian Jurisdictions | OEL (ppm) |
|---|---|
| Canada Labour Code | 2 [sk] |
| BC, AB, MB, NL, PE, NB, NS | 2 [sk] |
| ON | 2 [sk] 10 [c] |
| NT, NU, SK | 2 [sk] 4 [stel] |
| QC | 2 [sk, em] |
| YT | 20 [sk] 30 [stel] |
| Other Jurisdiction | OEL (ppm) |
| ACGIH 2020 TLV | 2 [sk] |
ppm = parts per million
sk = easily absorbed through the skin
c = ceiling (not to be exceeded at any time)
stel = short term exposure limit (15 min. maximum)
em = exposure must be reduced to the minimum
ACGIH = American Conference of Governmental Industrial Hygienists
TLV = threshold limit value
Canadian environmental guidelines and standards*
| Jurisdiction | Limit | Year |
|---|---|---|
| BC’s Contaminated Sites Regulation, BC Reg 375/96 | Sets soil standards for the protection of human health: Agricultural and low density residential sites: 15 μg/g Urban park and high density residential sites: 25 μg/g Commercial and industrial sites: 60 μg/g Drinking water: 5 μg/L Sets vapour standards for the protection of human health: |
2020[22] |
| Ontario Ambient Air Quality Criteria | Annual: 0.12 µg/m3 24 hour: 0.6 µg/m3 |
2016[23] |
| Alberta Ambient Air Quality Objectives | Annual: 2 µg/m3 1 hour: 43 µg/m3 |
2017[24] |
| Quebec’s Clean Air Regulation | 1 year limit: 12 µg/m3; Prohibited discharge into the air if the concentration of acrylonitrile exceeds the standard | 2011[25] |
| Ontario’s Air Pollution – Local Air Quality Regulation Standards | 24-hour standard: 0.6 µg/m3; Prohibited discharge into the air if the concentration of acrylonitrile exceeds the standard | 2020[26] |
*Standards are legislated and legally enforceable, while guidelines (including Ontario ambient air quality criteria) describe concentrations of contaminants in the environment (e.g. air, water) that are protective against adverse health, environmental, or aesthetic (e.g. odour) effects
Canadian agencies/organizations
| Agency | Designation/Position | Year |
|---|---|---|
| Health Canada | DSL – low priority substance (already risk managed) | 2006[27] |
| CEPA | Schedule 1, paragraph ‘c’ (human health) | 1999[28] |
| Environment Canada | Pollution Prevention Plans – Part 4 of CEPA 1999 | 2003[2] |
| National Classification System for Contaminated Sites | Rank = “High hazard”, potential human carcinogen | 2008[29] |
| Environment Canada’s National Pollutant Release Inventory | Reportable to NPRI if manufactured, processed, or otherwise used at quantities greater than 1,000 kg | 2016[30] |
DSL = domestic substance list
CEPA = Canadian Environmental Protection Act
Acrylonitrile was not included in other Canadian government guidelines, standards, or chemical listings reviewed.
Main Uses
Acrylonitrile is widely used in a variety of industrial applications.[1] For example, it is used extensively to manufacture acrylic fibres, resins, plastics, and nitrile rubbers.[1] Common resins containing acrylonitrile include acrylonitrile-butadiene-styrene (ABS), which is used in business machines and construction material, and styrene-acrylonitrile (SAN), which is used in automotive applications, household goods, and packaging.[1]
Acrylonitrile is also a significant chemical intermediate in producing adiponitrile (used to produce nylon) and acrylamide.[5] Specialty applications of acrylonitrile include producing carbon fibres that reinforce composites for aircraft and the aerospace industry.[5]
Historically, acrylonitrile was used as a pesticide when mixed with carbon tetrachloride;[2] using acrylonitrile as a pesticide ceased in Canada in 1976.[3]
Canadian Production and Trade
Acrylonitrile is not produced in Canada, but it is imported to produce adiponitrile, nitrile-butadiene rubber, diamines, ABS polymers, styrene-acrylonitrile (SAN) polymers, and styrene-butadiene latex.[31] Most acrylonitrile (2,750 tonnes) is imported from the United States and is used during the production of SAN foams and polymers, acrylic emulsion, and diamines.[31,32]
Production and trade
| Activity | Quantity | Year |
|---|---|---|
| Export | 0 t (of ‘Acrylonitrile’) | 2021[33] |
| Import | 2,546 t (of ‘Acrylonitrile’) | 2021[33] |
t = tonne
Environmental Exposures Overview
According to Health Canada, the main route of exposure to acrylonitrile for the general population is indoor air, followed by ambient air.[34] Exposure is expected to be higher near industrial point sources.[2]
Children may be exposed to higher levels than adults. This may be due to their lung surface to body weight ratio, lower excretion rates, and because concentrations may be higher closer to the ground (acrylonitrile is heavier than air).[2,35]
In Canada, the two major sources of acrylonitrile released into the environment are the organic chemical industry (97.4%) and municipal wastewater treatment facilities (2.6%).[2,34] During the 1990s, most acrylonitrile releases reported to the NPRI were from synthetic rubber manufacturers, although this sector voluntarily decreased their emissions by 66% between 1994 and 1999, primarily because one company controlled its fugitive emissions.[2]
In 2003, under CEPA 1999, notice was published in the Canadian Gazette requiring the synthetic rubber industry to prepare and implement Pollution Prevention Plans to reduce acrylonitrile emissions to the lowest achievable levels.[36] Emissions from plastic manufacture, however, have risen substantially since 2000, such that total emissions in 2006 were over four times the emissions in 2000.[37]
Tobacco smoke contributes to indoor air levels of acrylonitrile. In 1990, the ATSDR speculated that cigarette smoking would no longer be a major source of exposure since acrylonitrile use as a fumigant on stored tobacco crops had been discontinued.[2] Recent studies, however, report that acrylonitrile is emitted directly from cigarettes,[38] and that tobacco smoke is a significant source of acrylonitrile in indoor air.[38] Levels of acrylonitrile may remain elevated for several hours after smoking has ceased.[39]
In the past, vehicle exhaust was also a source of acrylonitrile. With the improved catalysts in engines today, little if any acrylonitrile is expected to enter the environment in this way.[34]
There is limited data to assess exposure to acrylonitrile via food.[34] Health Canada reports that the packaging is not currently extensively used in Canada in cases where food is in direct contact.[34]
The sale of food containing acrylonitrile is prohibited under the Food and Drug Act.[34] Acrylonitrile has not been detected above trace amounts in Canadian ambient surface water or drinking water.[3]
Searches of Environment Canada’s National Pollutant Release Inventory (NPRI) and the US Consumer Product Information Database yielded the following results on current potential for exposure to acrylonitrile in Canada:
NPRI and US Consumer Product Information Database
| NPRI 2015[37] | ||
|---|---|---|
| Substance name: ‘acrylonitrile’ | ||
| Category | Quantity | Industry |
| Released into Environment | 6.5 t | Plastic product manufacturing Paint, coating and adhesive manufacturing Other chemical product manufacturing (8 facilities) |
| Disposed of | 1.4 t | |
| Sent to off-site recycling | None | |
| US Consumer Products 2016[40] | ||
|---|---|---|
| Search Term | Quantity | Product Type |
| ‘acrylonitrile’ | 6 | Sealant (3); Spackle (3) |
| ‘acrylonitrile polymer’ | 1 | Auto defogger (1) |
| ‘acrylonitrile copolymer’ | 10 | Olay® (9) and Gillette® (1) body washes |
| ‘ABS copolymer’ | 4 | cement (4) |
t = tonne
Occupational Exposures Overview
Inhalation and dermal contact are the most important routes of occupational exposure.[3]
CAREX Canada estimates that 4,100 Canadians are exposed to acrylonitrile in the workplace. The largest industrial groups exposed are plastic product manufacturing, followed by rubber product and motor vehicle parts manufacturing. Occupations that are most exposed to acrylonitrile include plastic processing machine operators, rubber processing machine operators, and plastic products assemblers, finishers, and inspectors.
A risk assessment by the EU summarized European occupational exposure data and identified the highest mean exposures in fibre production, although they were still ≤ 1 ppm.[41] Further exposures can occur during industrial processes such as burning synthetic polymers, working with glues and adhesives, and firefighting.[42] Firefighters may be exposed to acrylonitrile because the chemical can be released from burning plastics.[42] However, acrylonitrile is very flammable itself and is likely to burn off in a fire, producing hydrogen cyanide, another very toxic gas.[3]
For more information, see the occupational exposure estimate for acrylonitrile.
